Features:

• Source or sync up to 180W of DC or pulsed power ( /-3000V@20mA, /-1500V@120mA)
• 1fA low current resolution
• Dual 22-bit precision ADCs and dual 18-bit 1µs per point digitizers for high accuracy and high speed transient capture
• Fully TSP compliant for easy system integration with Series 2600B System SourceMeter models
• Combines a precision power supply, current source, DMM, arbitrary waveform generator, V or I pulse generator, electronic 18-bit load, and trigger controller-all in one instrument
• Includes TSP® Express characterization software, LabVIEW driver, and Keithley's Test Script Builder software development environment

Applications:

• Power semiconductor device characterization and testing
• Characterization of GaN, SiC, and other compound materials and devices
• Breakdown and leakage testing to 3 kV
• Characterization of sub-millisecond transients
