Product Description

• High quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditions

• Automatic internal bypass

• Pure static bypass switch without bridging contactor securing a fast and reliable transfer to and from bypass, rated for 125% nominal load

• Automatic restart of loads after UPS shutdown

• Automatically starts up the connected equipment upon the return of utility power

• ECO Mode

• Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection

• EPO

• Attach the device to an Emergency Power Off (EPO) system so that power can be turned off in an emergency situation

• Intelligent battery management

• Maximizes battery performance, life, and reliability through intelligent, precision charging

• Intelligent Card Slot

• Customize UPS capabilities with management cards

• LCD graphics display

• Text and mimic diagrams that display modes of operation, system parameters and alarms

• Rack/Tower convertible

• Protects the initial investment in the UPS when migrating from tower to rack-mount environment

• Serial connection

• Use your PC to access additional power protection and management features for your UPS via a serial port

• USB connection

• Use your PC to access additional power protection and management features for your UPS via a USB Port

• Easy UPS On-Line Features & Benefits

• Availability

• Intelligent battery management

• Maximizes battery performance, life, and reliability through intelligent, precision charging

• Features

• Double conversion on-line topology

• Guarantees a consistently high level of power quality. Any disturbances on the distribution waveform are regenerated via the zero transfer time AC to DC then DC to AC conversion process

• The battery is only used as a back-up source

• Allows the user to manage the UPS functions, schedule automatic shutdown and monitor the power grid occurrences through an interactive interface that ensures an easy and intuitive monitoring

• Management Software

• Safety-agency approved

• Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment

• Pure sine wave output on battery

• Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics

• Management Software

• Allows you to easily monitor your utility power and manage your UPS

• Intuitive LCD interface

• Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys

• Input power factor correction

• Minimizes installation costs by enabling the use of smaller generators and cabling

• High efficiency

• High efficiency rates that remain stable even at lower operating power levels

• Generator compatible

• Ensures clean, uninterrupted power to protected equipment when generator power is used

• ECO Mode

• Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection

• Manageability

• LED Indicators

• Provide easy-to-read status of the unit and utility power conditions

• LCD graphics display

• Text and mimic diagrams that display modes of operation, system parameters and alarms

• Intelligent Card Slot

• Customize UPS capabilities with management cards

• Serial connectivity

• Provides management of the UPS via a serial port

• Network manageable

• Most models provide remote power management options of the UPS over the network

• Many do not have NMC embedded

• Serviceability

• Disconnected battery notification

• Warns when a battery is not available to provide backup power

• Automatic self-test

• Periodic battery self-test ensures early detection of a battery that needs to be replaced

• Audible alarms

• Provides notification of changing utility power and UPS power conditions

• Predictive failure notification

• Provides early-warning fault analysis ensuring proactive component replacement

Product Specification

Brand	APC
Product Type	UPS
Model	SRV6KUXI-IN
Output
Output Power Capacity	6.0kWatts / 6.0kVA
Max Configurable Power (Watts)	6.0kWatts / 6.0kVA
Nominal Output Voltage	230V
Output Voltage Note	Configurable for 220 : 230 or 240 nominal output voltage
Efficiency At Full Load	94.0 %
Output Voltage Distortion	1 %
Output Frequency (Sync To Mains)	50/60 Hz /- 3 Hz Sync to mains
Other Output Voltages	220 V, 240 V
Load Crest Factor	3 : 1
Topology	APC Easy UPS On-Line SRV 6000VA RT No Battery 230V SRV6KUXI-IN Title: DefaultTitle $ 54.77 $ 42.13 Please select combo product attributes The combo subtotal is $,SAVE$ Unavailable Add to Cart Buy It Now You May Also Like $ 78.65 Vapor Zone3 Photochromic Swimming Goggles $ 74.92 $ 57.63 Helmet POC Octal MIPS Matte Red $ 106.55 $ 88.78 Leviton N1303-TDS 30A 600VAC 3 Pole Manual Motor Controller in Thermoplastic Enclosure - Industrial Grade $ 72.85 $ 56.04 The ND Selects Filter Kit Plus $ 57.43 $ 44.18 Siemens 6ES73221FH000AA0 $ 88.52 $ 68.09 Waldmann 113178005, Omnivue LED Magnifier Light, 6.5 in. x 4.25 in. Lens, 35" Art. Arm, 3 Diopter, 2 prong plug $ 85.88 $ 66.06 Addon Avago Afbr-720Xpdz Compatible Taa Compliant 10Gbase-Sr Xfp Transceiver (Mmf, 850Nm, 300M, Lc, Dom) $ 83.03 $ 63.87 TITANIUM USA RT5 FULL COMMERCIAL TREADMILL $ 79.87 Addon Calix 100-01669-C Compatible Taa Compliant 1000Base-Bx Sfp Transceiver (Sm $ 79.95 $ 49.95 Red & Green Christmas Collage™ Laser Projector ＋ Home VR Accessories ＋ 360-Degree Motion Controllers Wireless Systems ＋ Bluetooth VR Sync Devices Accessories ＋ Lens Cleaning Kits Comfort Head Straps Sensors ＋ Body Positioning Modules Environment Tracking Sensors Lighting ＋ Headset Sync Indicators Cart ＋ Your cart is currently empty. Total: VIEW CART
