Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Current, Load | 15 A rms |
| Depth | 0.079" (2mm) |
| Dimensions | 45.7 x 23 x 58.4 mm |
| Height | 2.299" (58.4mm) |
| Length | 1.799" (45.7mm) |
| Minimum Load | 0.15 A rms |
| Relay Type | General Purpose Relay |
| Series | |
| Standards | CE, CSA LR81689-73, RoHS Compliant, UL 116950 |
| Switch Type | DC Switching |
| Temperature Operating Range | -30 to 80 °C |
| Terminal Type | Screw |
| Voltage, Control | 2 to 7 VDC |
| Voltage, Load | 100 to 240 V rms |
